Product Characteristic:
1¡¢Control Mode: SAPWM vector control.
2¡¢0.00¡«400.00Hz Output frequency range:0.00~400HZ
3¡¢ Instruction Passage Mode: Operator Panel , Terminal Control, Long-distance communication control.
4¡¢ Frequency setting the signal :number keyboard , Analog setting ( current , voltage signal ). Long-distance setting , Multi-Phase speed setting. Terminal assembled . PID closed-loop setting.
5¡¢ big Jump-start torque: 0.5 HZ/150%
6¡¢1.0K¡«10.0KHz Carrier frequency range:1.0K~10KHz
7¡¢ DC Current Braking : Start and Stop DC current braking can be adjusted solely.
8¡¢Speed control precision: ¡À0.5% the top speed (SVC) Automatism voltage modulate: ( AVR): Can keep output voltage invariableness automatically when the power net and voltage changes.
9¡¢Automatism restrict current : can restrict the Maximum current of the motor. And can protect the inverter and the motor reliably.
10¡¢PLC program control: Single Cycle, continuous loop, wobble control and are fit for all kinds of field¡¯s demand.
11¡¢ Input ,output terminal are programmable and are convenient for user.
12¡¢ Analog signals output , voltage and current can be selected.
 |
